CNC 4P RCCB Residual Current Circuit Breakers YCB6HLE-63

General

1.      Protection

1. Provides dependable protection against overload circumstances and short-circuit currents, therefore safeguarding electrical circuits and equipment.
2. Fault Current
Shields against the negative consequences of sinusoidal alternating earth fault currents, therefore reducing electrical shock dangers.
3. Electrical Risks
Provides further direct contact protection as well as safety against indirect touch, therefore safeguarding those from electrical risks.
4. Insulation Problems
Reducing the danger of fire threats brought on by insulation problems helps to improve the safety of electrical systems.

Usually found in residential buildings, they offer necessary protection for families and houses.
5. Type
Type Classification for Instantaneous Release: Classified based on the instantaneous release type including:

Type B using 3-5 times rated current, Iₙ,

Type C, 5–10 times rated current, Iₙ ;

Based on the application, Type D (10-20 times rated current, Iₙ) provides different degrees of protection.

Features:

• Protection against Remnant Currents:

The RCBO stops earth leakage currents, which stops fires caused by damaged insulation or wires.
• Putting overcurrent protection (overload and short circuit) and residual current prevention (residual current) in the same device makes electrical systems completely safe.

• Instantaneous Tripping:

 The RCBO quickly protects against possible dangers when the residual current goes over the set number or when there is an overcurrent.

The RCBO is made to be small so that it can fit into regular circuit boards without taking up a lot of space.
• It's easy to put in the circuit, so it can be used in homes, businesses, and factories.
• Safety Compliance:

It makes sure that laws, like IEC/EN 61009, are followed and provides dependability in line with world safety standards.
It offers two types of security: overcurrent protection and earth leakage protection. This keeps people and equipment safe from electrical problems.
• Preventive Action:

If there is an earth leak, the RCBO cuts the circuit off right away. This lowers the risk of electric shock and fire.

Applications:

• Residual Current Protection:

The RCBO stops earth leakage currents, therefore preventing fires started by defective wiring or broken insulation.
Complete safety for electrical circuits results from combining residual current prevention in one device with overcurrent protection—overload and short circuit.

• Instantaneous Tripping:

When the residual current exceeds the set value or when an overcurrent develops, the RCBO offers quick protection against possible risks.
The RCBO is designed to be tiny so it might fit into standard distribution boards without using much space.
• Simple circuit installation offers flexibility for industrial, household, and commercial purposes.
• Safety Compliance:

It provides dependability in line with worldwide safety norms and guarantees legislation compliance with IEC/EN 6100.

Combining overcurrent prevention with earth leakage protection provide dual protection, therefore sheltering equipment from electrical faults as well as people.
• Preventive Action:

The RCBO quickly cuts the circuit in response to earth leakage, therefore reducing the risk of electric shock and fire hazards.
