Huawei inverter 50 kw On-Grid Solar Inverter

PDF Document

OVERVIEW:

The Huawei SUN2000-60KTL 60kW 3phase Solar Inverter series of products uses three-level circuit topology, the maximum efficiency up to 98.9%, Photon test result is A+/A+ at both of high irradiation and medium irradiation. The six MPPT is adaptable and flexible for building roof-top PV plant design to improve system yields. DC&AC lightning protection module integrated and natural cooling effectively improve product reliability.

This Huawei SUN2000-60KTL 60kW 3phase Solar Inverter  has good environment adaptability and can be used for various scenarios covering from 60kW to Megawatts, either rooftop or ground mounted power plants.

Features:

Smart:

• 12 strings intelligent monitoring and fast trouble-shooting

• Power Line Communication supported

• Smart I-V Curve Diagnosis supported

Efficient:

• Max. efficiency 98.9%, European efficiency 98.7% (@480 V)

• Max. efficiency 98.7%, European efficiency 98.5% (@380 V / 400 V)

• 6 MPPT per unit, effectively reducing  string mismatch

Safe:

• DC switch integrated, safe and convenient for maintenance

• Residual Current Monitoring Unit (RCMU) integrated

• Fuse free design

Reliable:

• Natural cooling technology

• Protection degree of IP65

• Type II surge arresters  for both DC and AC
