CNC AC SPD CARTRIDGE, 385V In=20KA Imax=40KA YCS6-B

AC Surge Protection Devices YCS6-B ( CARTRIDGE )

The YCS6-B series Surge Protection Device, an AC SPD CARTRIDGE, is suitable for TT, IT, TN-S, TN-C, and TN-C-S, the power supply system with the rated voltage up to 230/400V and AC 50/60Hz. Its design corresponds to IEC61643-1. The product is usually installed in the incoming line low voltage distribution box of the building, and it can release 100kA lightning stroke current.

General

●      The YCS6-B Surge Protection Device is designed to protect electrical installations from transient overvoltage caused by lightning or switching operations.

●      It ensures the protection of low-voltage equipment, preserving the longevity and functionality of sensitive devices.

●      The device meets international standards like IEC61643-1, ensuring its reliability and high performance.

AC SPD Cartridge Key Features

1. Enhanced Surge Protection for Electrical Systems
The YCS6-B Surge Protection Device offers high efficiency in protecting electrical circuits from harmful surge events.

●      Nominal discharge current (In) up to 20kA.

●      Maximum discharge current (Imax) can handle up to 40kA.

2. Robust Lightning Surge Defense
Ac SPD CARTRIDGE Designed to absorb and redirect lightning-induced surges, safeguarding electrical infrastructure.

●      Can withstand lightning stroke currents of up to 100kA.

●      Protects sensitive electronic devices from power surges.

3. Versatile Compatibility with Power Supply Systems
Ideal for use in multiple types of electrical networks, ensuring widespread application.

●      Compatible with TT, IT, TN-S, TN-C, and TN-C-S systems.

●      Suitable for AC 50/60Hz systems with voltages up to 230/400V.

4. Simple Installation for Quick Deployment
Easy to integrate into existing power setups, ensuring effective protection with minimal effort.

●      Designed to be installed in low-voltage incoming line distribution boxes.

●      Quick installation process for immediate surge protection.

Specifications

●      Type: YCS6-B (CARTRIDGE)

●      Nominal Discharge Current (In): 20kA

●      Maximum Discharge Current (Imax): 40kA

●      Continuous Operating Voltage (Uc): 385V

●      Standard: IEC/EN 61643-1

●      Certificate: CE

Brand

CNC
