CNC 3 Phase YC6VAZs Electronic Phase Switch
CNC 3 Phase YC6VAZs Electronic Phase Switch
CNC 3 Phase YC6VAZs Electronic Phase Switch

CNC 3 Phase YC6VAZs Electronic Phase Switch

Product Details General Function   description: When   a   phase   of   L1,L2,L3   overvoltaged,undervoltaged   or phase lacked,the relay...
Vendor: CNC Electric Pakistan
Availability: In Stock
Rs.8,900.00
Rs.9,700.00
Rs.8,900.00
Save Rs.800.00
(-8%)
10 customers are viewing this product
Ampre: 63A
Why Shop With Us?
⏰

EXPRESS DELIVERY

Same Day Delivery in Lahore . Order Before 4 PM.

STANDARD DELIVERY

Reliable Delivery in
2 to 4
Working Days.

PRODUCT WARRANTY

Trusted Products with 2 years Replaced Warranty.

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
CNC 3 Phase YC6VAZs Electronic Phase Switch

CNC 3 Phase YC6VAZs Electronic Phase Switch

Rs.9,700.00 Rs.8,900.00
CNC 3 Phase YC6VAZs Electronic Phase Switch
CNC 3 Phase YC6VAZs Electronic Phase Switch
CNC 3 Phase YC6VAZs Electronic Phase Switch

CNC 3 Phase YC6VAZs Electronic Phase Switch

Rs.9,700.00 Rs.8,900.00
Ampre: 63A
Description

Product Details

General

Function   description: When   a   phase   of   L1,L2,L3   overvoltaged,undervoltaged   or phase lacked,the relay will be disconnected and automatically search for the normal phase,and   switch   to    open   the    relay   of   the    normal   phase,switching    priority L1>L2>L3!

Technical Date

Model

YC6VAZs

Rated Supply voltage

AC 220V

Operation voltage

AC 80V-400V(single phase)

Rated frequency

50/60Hz

Electric current(>A)setting range

63A/80A/100A

Overyoltage(>U)setting rang

230-30

Undervoltage(<U)setting range

110-210V

Reset/start delay

=30S

Voltage measurement accuracy

2%(Not exceeding 2%of the overall range)

Rated insulation voltage

400

Output contact

1N0

Electrical life



Mechanical life

10⁶

Protection degree

P20

Pollution dearee



Altitude

7000o

Operatintg temperature

50℃~55℃

Humidity

<50%at 40℃(withou  condensation)

Storage temperature

30℃ 70℃

Current Specification

63A

0A

00A

Rated Operating current(In,A)

53



OA

Max Operating Current Imax(A,within 10min)







Max power of load (KW)

13.9KW

17.6KW

22KW



Default Setting



Technical Parameter

Setting range

Step

Factory Setting

Over-voltage protection value

AC230V-300V

V

AC270V

Under-voltage protection value

AC210V-140V

1V

AC170V

Recovery delay time

1S-30S

1S

1S



Function Setting

Overall and mounting dimensions
